| Specification/ Machine model | Unit | MT-16 | MT-20 |
|---|---|---|---|
| X axis travel | mm (in) | 2800(110.2) | 3200(125.9) |
| Y axis travel | mm (in) | 2600(102.3) | 3000(118.1) |
| Z axis travel | mm (in) | 800(31.4) | |
| Max. diameter | mm (in) | 1600(62.9) | 2000(78.7) |
| Max.turning radius of gyration of area | mm (in) | 2100(82.6) | 2500(98.4) |
| Max. height of turning | mm (in) | 700(27.5) | |
| Max. width of milling | mm (in) | 2300(90.5) | 2700(106.2) |
| Max. height of milling | mm (in) | 900(35.4) | |
| Table loading | kg (lb) | 12000 (26455) | 15000(33069) |
| Spindle motor power | kW (HP) | 22/26 (30/35) | |
| The highest rotational speed of Vertical milling | rpm | 10-6000(0.39-236.2) | |
| The highest rotational speed of Horizontal milling | rpm | 10-2400(0.39-94.4) | |
| Spindle taper | BT#50 (ISO 50) | ||
| Rapid feedrate - X axis | mm(in)/min | 18000(708.6) | 15000(590.5) |
| Rapid feedrate - Y axis | mm(in)/min | 18000(708.6) | 15000(590.5) |
| Rapid feedrate - Z axis | mm(in)/min | 15000(590.5) | |
| Cutting federate | mm(in)/min | 1-10000 (0.04-393.7) | |
| Capacity of tool magazine | pcs | 32 | |
| Max. diameter of tool / Adjacent pocket empty | mm (in) | 127/215(5/8.4) | |
| Max. length of tool | mm (in) | 400(15.7) | |
| Max. weight of tool | kg (lb) | 20(44) | |
| Positioning accuracy (JIS 6338) | mm (in) | ±0.015(0.000591)/ full travel | |
